Cardiff University | Prifysgol Caerdydd ORCA
Online Research @ Cardiff
WelshClear Cookie - decide language by browser settings

Effectively regulating electrooxidation of formic acid over bimetallic PtCo alloys via the integration of theory and experiment

Zheng, Zhikeng, Liu, Bin, Qiu, Jiaxiang, Xu, Shaojun, Wang, Yuchen, Zhang, Man, Li, Ke, Sun, Zhongti, Li, Ziang, Wan, Yangyang, Catlow, C. Richard A. ORCID: https://orcid.org/0000-0002-1341-1541 and Yan, Kai 2024. Effectively regulating electrooxidation of formic acid over bimetallic PtCo alloys via the integration of theory and experiment. ACS Catalysis 14 (24) , pp. 18333-18344. 10.1021/acscatal.4c06198
Item availability restricted.

[thumbnail of zheng-et-al-2024-effectively-regulating-PP.pdf] PDF - Accepted Post-Print Version
Restricted to Repository staff only until 27 November 2025 due to copyright restrictions.

Download (1MB)

Abstract

Challenges in directly regulating the reaction pathways in the electrooxidation of formic acid have hindered widespread applications in direct formic acid fuel cells (DFAFCs). Hence, we report directly tuning the reaction pathway of formic acid oxidation (FAO) to avoid CO poisoning over the bimetallic PtCo alloys. The PtCo alloys are fabricated by using a facile one-step microwave method, avoiding the use of organic solvents and minimizing environmental pollution. The Pt1Co1 alloy displays a specific surface area of 17.58 m2 g–1 and exhibits a 121-fold increase in mass activity (1.18 A mgPt–1) compared to its counterpart Pt (<0.01 A mgPt–1). It also far outperforms Pt3Co1 (0.09 A mgPt–1) and Pt1Co3 (0.95 A mgPt–1) alloys. In situ attenuated total reflection infrared spectra further confirm that the bimetallic PtCo alloys catalyzed FAO through the direct pathway to CO2 formation, suggesting that adding Co plays a crucial role in enhancing Pt’s resistance to CO poisoning. Density functional theory calculations further indicate that the incorporation of Co into the Pt coordination environment is crucial for altering the formation of transition intermediates, which can form a more stable bond with the HCOO intermediate, which is formed by breaking the O–H bond. Specifically, on the Pt1Co1 alloy with 50% Co incorporation, the free energy for HCOO* formation is significantly lower (−0.296 eV) compared to that of COOH* (0.028 eV). This trend is reversed when compared with pure Pt (0.196 eV for HCOO* and −0.190 eV for COOH*), thereby promoting FAO via a direct pathway. This work provides a reference for the rational development of high-efficiency Pt-based alloy electrocatalysts.

Item Type: Article
Date Type: Publication
Status: Published
Schools: Cardiff Catalysis Institute (CCI)
Chemistry
Publisher: American Chemical Society
ISSN: 2155-5435
Funders: National Natural Science Foundation of China, Jiangsu University, EPSRC
Date of First Compliant Deposit: 6 January 2025
Date of Acceptance: 20 November 2024
Last Modified: 06 Jan 2025 11:00
URI: https://orca.cardiff.ac.uk/id/eprint/174697

Actions (repository staff only)

Edit Item Edit Item

Downloads

Downloads per month over past year

View more statistics
