Effective InAsP dislocation filtering layers for InP heteroepitaxy on CMOS-standard (001) silicon

Liu, Shangfeng, Ratiu, Bogdan-Petrin, Jia, Hui, Yan, Zhao, Wong, Ka Ming, Martin, Mickael, Tang, Mingchu, Baron, Thierry, Liu, Huiyun and Li, Qiang ORCID: https://orcid.org/0000-0002-5257-7704 2024. Effective InAsP dislocation filtering layers for InP heteroepitaxy on CMOS-standard (001) silicon. Applied Physics Letters 125 (8) , 082102. 10.1063/5.0219507

Preview

PDF - Published Version Available under License Creative Commons Attribution. Download (2MB) | Preview

Abstract

In this work, we report InAsP-based dislocation filter layers (DFLs) for InP heteroepitaxy on CMOS-standard (001) Si substrates, demonstrating a threading dislocation density of 3.7 × 107 cm−2. The strain introduced by InAsP induces dislocation bending at the InAsP/InP interface, thereby facilitating the reaction and annihilation of dislocations during their lateral glide. Concurrently, the InP spacer exhibits tensile strain, leading to the formation of stacking faults (SFs). With a comprehensive analysis utilizing x-ray diffraction, electron channeling contrast imaging, and transmission electron microscopy, the effects of DFL-induced strain on dislocations and SFs are investigated. Fine-tuning the strain conditions allowed low-dislocation-density while SF-suppressed, anti-phase boundary free InP on Si. This work, therefore, provides a useful buffer engineering scheme for monolithic integration of InP-based electronic and photonic devices onto the industry-standard silicon platform.
